MEGA-T400A Automated Abrasive Cutter
The MEGA-T400A offers versatile cutting with advanced automation and manual control. Its touch screen interface ensures intuitive operation and high precision. Built for demanding tasks, its durable design delivers reliable performance.
Features
- High precision manual cutting with minimal maintenance
- Robust design for industrial applications
- Easy operation with ergonomic controls
- Suitable for various materials including metals and ceramics
Technical Specifications - MEGA-T400A
| Parameter | Specification |
|---|---|
| Cut-off Blade Size | 16-inch (400 mm) |
| Operation | Auto / Manual |
| Screen | Touch |
| Arbor Size | 32 mm |
| Cutting Capacity (H x D) | Maximum 3 x 6-inch (70 x 150 mm) |
| Max Cutting Diameter | 6-inch (150 mm) |
| Wheel Feed | Manual |
| Table Feed | Auto / Manual |
| Y Pulse Feed | Auto |
| Y-axis Table Feed Range | 7-inch (180 mm) |
| Y-axis Feed Speed (Feed Rate) | 0.04 to 0.20-inch/second (1-10 mm/second) |
| X-axis Table Feed Range (Optional) | 1.8-inch (45 mm) |
| X-axis Feed Speed (Feed Rate) (Optional) | 0.04 to 0.07-inch/second (1-2 mm/second) |
| Vertical Movement (Z-axis) | 5-inch (125 mm) |
| T-slotted Table Dimensions | 11 x 18.25-inch (280 x 470 mm) |
| T-slotted Width | 0.5-inch (50 mm) |
| Cooling Unit | 14 gallons (53 liters) |
| Motor Power | Constant torque variable speed Servo Motor, 3φ - 4.5 KW/(5.8 hp) 208Y, 380Y, 480V - 15 KW (20 hp) 480V |
| Motor Speed | Variable (1000-3000 rpm) |
| Cutting Force (Current Settings) | 5-25 amps (480V) |
| Electrical Specification | 208Y / 380V or 480V 3-phase (50/60 Hz) |
| Dimensions (WxDxH) | Hood closed: 48 x 51 x 64-inch (1220 x 1300 x 1610 mm); Hood open: 48 x 51 x 66-inch (1200 x 1300 x 1700 mm) |
| Weight | 880 lbs (400 kg) |
| Catalog Number | MEGA-T400A |
