Ceramic Matrix Composites (CMC's)
Specimen Preparation (Class 10 Procedures)
Metallographic Class 10 sample preparation


Ceramic matrix composites are used for either their high temperature resistance or there low wear characteristics.

Preparation Challenge:

Specimen preparation of these materials requires that the brittle phases be maintained.

SiC fiber - Silicon Nitride Matrix
SiC fibers in Si3N4 matrix

Hafnium Diboride in a Boron Nitride Matrix
HfB2 fibers in BN matrix

SiC particles - Silicon Nitride Matrix
SiC particles in Si3N4 matrix

SiC particles - Zirconium Diboride Matrix
Metallographic micrograph of SiC Zirconium Diboride ceramic matric composite
